The BioCon-900 Bladder Scanner offers a wireless, non-invasive 3D ultrasound system that measures the volume of urine in a patient's bladder, using a real-time Pre-Scan function to locate the bladder before scanning for improved accuracy. It's available as a charger-only unit or bundled with a desktop docking station, with an optional barcode reader for patient ID input.
- Uses ultrasound signals to determine the bladder's outline and total volume of urine
- Real-time Pre-Scan function locates the bladder prior to scanning and improves the accuracy of results
- Immediate printout of results via the internal printer, or use the included CubeScan PC software to upload saved data for later review
- Dual frequency ultrasound probe (2MHz, 3.4MHz), B-mode scan image, 120° scan angle
- Rechargeable Li-ion battery, approximately 1500 scans per charge
- 3 Year Warranty with 5 year option available
- Display: TFT-LCD, 2.4 inch, Format: 240 x RGB x 320 stripe
- Range: 0-999ml, Accuracy +/- 15ml (0-999ml)
- Scan Time: Less than 3 secs
- External Interface: IrDA (Infrared Data Association)
- Patient ID Input: 1D/2D Barcode scan or image capture
- Ultrasound Probe: Dual frequency (2MHz, 3.4MHz), B-mode scan image, scan angle 120°, penetration depth (normal patient) 23cm
- Power: Rechargeable Li-ion battery, 3.6V, 5200mAh, charging time less than 6 hours, approx. 1500 scans per charge
