The Sonata Mobile Client Lifting Hoist (Manual) is a compact mobile lifter for everyday transfers between bed, chair and toilet, suited to hospital, residential and community care. With manual leg adjustment, a small manoeuvrable footprint, it carries a safe working load of 150kg and is proudly made in Australia.
Yokes and spreader bars are sold separately. The yoke shown in the main hoist image is for illustrative purposes only.
- The Sonata is ideal for transferring from bed to chair or toilet
- Appropriate for hospital, residential and community care
- Manual leg adjustment
- Complemented by a full range of client slings, covering all sizes from extra small to XX large
- Suits Loop, Pivot and Pivot Care E-Clip slings
- Compatible with standard spreader bar or tilt/pivot frame
- With a small footprint, coupled with light weight, the Sonata is highly manoeuvrable
- Options: Tilt Pivot Frame, 4-point Yoke, Scales (integrated or supplied as an optional extra with conversion kit)
- Australian made
- This is the manual version of the Sonata — an electric model is also available (SMSON01ELS)
- Base Length: 100.5cm
- External Base Width Closed: 60.5cm
- External Base Width Open: 107cm
- Internal Base Width Closed: 51cm
- Internal Base Width Open: 97.5cm
- Base Width Adjustment: 3 Position Manual
- Under Bed Clearance: 13cm
- Minimum Height Yoke: 42cm
- Maximum Height Yoke: 173.5cm
- Average Lift Range: 87cm
- Lifter Weight: 41kg
- Minimum Storage Height: 126cm
- Under Base Height: 5.5cm
- Maximum Hoist Reach: 87.5cm
- Minimum Hoist Reach: 55.5cm
- Safe Working Load: 150kg
